Meizu Pro 7 Plus: Dual-cam and dual-screen powerhouse

The Meizu Pro 7 Plus is the Chinese manufacturer’s latest flagship smartphone, packing plenty of processing power for photography enthusiasts via the MediaTek Helio X30 chipset, deca-core processor, and 6GB RAM. The camera setup boasts a dual-cam solution that features two 1/2.9″ 12Mp sensors (RGB + monochrome) with 1.25µm pixel pitch. In theory, the two sensors combine for improved depth effects and overall image quality.

An interesting feature for mobile photographers is a second AMOLED display on the back of the device. As well as being handy for quickly checking the time or notifications, the second display can also be used as a viewfinder to shoot nicely-composed selfies while still using the high-quality rear camera. A background-blurring bokeh mode is on board as well. We tested the Meizu Pro 7 Plus with firmware version Flyme 6.1.2.0A. Let’s see how it shapes up in our DxoMark Mobile tests.

Key camera specifications:

• Dual cameras with 12Mp RGB & monochrome sensors
• Sony Exmor 1/2.9″ IMX368 sensors with 1.25µm pixel pitch
• f/2.0-aperture lens
• Phase-detect autofocus
• Two-tone flash
• 4K 2160p@30fps video

About DxOMark Mobile tests: For scoring and analysis in our smartphone camera reviews, DxOMark engineers capture and evaluate over 1500 test images and more than 2 hours of video both in controlled lab environments and in natural indoor and outdoor scenes. This article is designed to highlight the most important results of the testing. For more information about the DxOMark Mobile test protocol, click here.

Test summary

Securing an overall DxOMark Mobile Score of 71 points, the Meizu Pro 7 Plus produces better results for still photos, for which the device achieves a Photo score of 74. The device gets many of the basics right, with good results for exposure, color, autofocus, flash, and noise, so successful images are possible. Artifacts are a significant problem, however, particularly inconsistent sharpness across the frame, either partially or completely corrupted files displaying no picture, as well as some frames captured at a much lower resolution for no obvious reason.

The Meizu’s overall mobile score was watered down a little by its video performance, which achieved a lower score of 65. Its key strengths for video are bold and pleasant colors, with generally accurate white balance and smooth adaptation. Video exposure is mainly good in well-balanced conditions, but dynamic range is limited for both video and still photos when shooting high-contrast scenes, and videos shot in low-light conditions are noticeably underexposed. Autofocus performance is fast to lock on, but inconsistent during recording, and although stabilization is effective when you’re fairly stationary, videos on the move are a little trickier for the Meizu to handle.

Bright light

We achieved many successful pictures shooting natural scenes outdoors, with good exposure in well balanced lighting conditions, nice color rendering, and acceptable white balance. Some warmer color casts were evident, but they weren’t unpleasant, giving areas drenched in sunlight a nice glow. Dynamic range is limited when shooting in default mode, as the Meizu’s HDR mode doesn’t kick in automatically, so high-contrast scenes remained challenging, with significant loss of detail in the highlights and shadows. Texture is acceptable in static scenes outdoors, when the autofocus system finds good focus and when you don’t jab the screen too hard (more on this later), but even in the best examples, the Meizu Pro 7 Plus doesn’t capture the finest details.

The Meizu Pro 7 Plus is capable of good exposures in bright outdoor lighting conditions, with accurate test chart results under consistent lighting in the lab, as well as some nice results in our outdoor test scenes when the light was well-balanced.

Low light and Flash

In lower light conditions, exposures start to get a little dark, especially in very low light, where a loss of color saturation is evident, but in fairly bright indoor conditions, exposures remain very acceptable. When exposure is good, color rendering is generally nice, but some color shading with green tones towards the center shifting to pink at the edges is evident under some artificial light sources. Noise is well-controlled in low light, and better than that of many key competitors, with smooth rendering in homogenous areas even in very low light. Texture is pretty good in darker conditions, too, particularly in static scenes, although capturing good detail in moving subjects in low light remains elusive for the Meizu Pro 7 Plus.

The Meizu Pro 7 Plus is capable of good exposures in indoor lighting conditions, with accurate test chart results in the lab using consistent lighting, as well as some nice results in our outdoor test scenes where the lighting conditions were well balanced.

Using flash as the only light source, color remains good, albeit with a slight green white balance cast. The flash is well-centered in the frame, but visible corner shading occurs, with a noticeable buildup of luminance noise towards the edges, and sharpness is fairly low. Mixing flash with additional light sources, the green white balance cast intensifies and portraits tend to suffer from the red eyes, reddish skin tones, and a loss of sharpness.

Using flash as the only light source, white balance and color are fairly good, although a slight yellow/green cast is visible on skin tones, and sharpness is fairly low. A buildup of luminance noise is also visible in the corners, along with some slight corner shading.

Zoom and Bokeh

With no second telephoto lens on the Meizu Pro 7 Plus for zoom, photographers must rely on conventional digital zoom to get a bit closer to subjects. At close range at 2x magnification, results are pretty good, particularly in bright light: overall detail preservation is strong, but we advise some phone support or very sturdy handling for shooting 2x zoom photos in low light. Shots at 4x in the very brightest conditions are just about acceptable, but expect to see some artifacts and to lose details. In low light at 4x, or in any lighting conditions at 8x, image quality is seriously affected.

The Meizu Pro 7 Plus features a bokeh simulation mode for blurring the background in portraits. The blur intensity is very strong, which can make for a striking effect, but it’s not very natural. The shape of the bokeh is pleasing in some areas, but depth estimation failures can result in visible artifacts around your subject.

The bokeh simulation effect on the Meizu Pro 7 Plus has a very strong blur intensity, and although spectral highlights have a pleasant circular shape, the overall effect is not very natural. Many artifacts are visible around the subject, too, with depth estimation failures leading to inconsistent subject masking.

Photo scores explained

The Meizu Pro 7 Plus achieves a total photo score of 74, which is calculated from its scores in tests that examine different aspects of its performance under varying lighting conditions. In this section, we’ll take a closer look at these image quality sub-scores.

Exposure and Contrast

Meizu Pro 7 Plus

74

The Meizu Pro 7 Plus achieves a pretty good score for exposure, thanks to accurate and repeatable exposures of color checker charts in our lab under consistent light sources. Dynamic range is limited when shooting tricky high-contrast scenes, however, where a loss of detail in both the highlight and shadow regions is significant in some exposures. Although the Meizu Pro 7 Plus does have a HDR mode, it doesn’t appear to activate automatically in default mode, which is how we test devices for consistency.

The dynamic range potential of the Meizu Pro 7 Plus proves limited when shooting tricky high-contrast test scenes, with very overexposed highlights in our “under the bridge” test scene. Some loss of detail in the shadow regions is evident, too.

The limited dynamic range was also evident in our backlit portrait scenes, where highlight detail outside was significantly overexposed. In this scene the autofocus also struggled to lock on, resulting in a slightly soft image.

In low-light conditions, exposures are good down to 20 Lux; and although at 5 Lux they’re slightly underexposed, resulting in a loss of color saturation, overall they remain acceptable for the conditions.

Lab-test chart exposures in very low-light conditions (5 Lux) are a little underexposed, but very acceptable, although the rendering of some colors is slightly inaccurate, with the loss of some color saturation evident, too.

Color

Meizu Pro 7 Plus

76

A good score for color, as the Meizu renders bold and vivid hues in most conditions, and particularly when shooting outdoors or in bright indoor conditions. White balance is mainly accurate, providing neutral results in many of our outdoor test scenes; and although a slight warm color cast was visible in some outdoor pictures, it isn’t overly strong and some photographers may like it.

White balance is mostly accurate in outdoor lighting, and although a warm cast is sometime visible, it’s not overly strong or unpleasant.

Color rendering is generally good in outdoor lighting conditions, with accurate and reasonably well-saturated color.

The Meizu lost points for very noticeable color shading in some conditions, however, specifically in low-light images or when shooting under certain light sources.

Color shading is well-controlled on outdoor images, but under some artificial light sources, a shift in color from green in the center to pink at the edges is visible, such as in the image above, shot in the lab using 100 Lux fluorescent lighting.

Autofocus

Meizu Pro 7 Plus

73

The Meizu Pro 7 Plus’s phase-detection system found focus quickly in all lighting conditions, so it scored well for autofocus. It lost points for repeatability, however, with the device failing to find the best sharp focus consistently across a consecutive series of 30 shots in the lab.

Shooting 30 consecutive frames in low light (20 Lux) in the lab, and defocusing each time, the Meizu Pro 7 Plus was quick to focus after both a short or a long delay, but sharpness was inconsistent, with some shots slightly or completely out of focus, particularly after a short delay.

Shooting our natural test scenes, this lack of sharpness was evident in many shots, which displayed a slight blur. Autofocus is also a little erratic, with the point of focus in the frame changing depending on the subject.

Autofocus accuracy can be a little inconsistent, with slightly out-of-focus results in many of our natural test scenes. The point on which the Meizu Pro 7 Plus focuses also often changes depending on the scene, so we ended up with several images a bit out of focus.

Texture

Meizu Pro 7 Plus

57

A weaker score overall for texture. Although the Meizu performed pretty well in bright light, it suffered some loss of detail in low light.

Shooting outdoor natural scenes, fine detail preservation is generally good in low-contrast areas, such as the brick work of the wall or the window balconies.

Shooting static scenes, very good detail is possible in bright light over 100 Lux and results are just about OK when shooting indoor images, but the loss of detail is more significant below 20 Lux. Scenes containing some subject motion remain challenging for the Meizu Pro 7 Plus, however. It achieves the best results in the brightest light, but even then some subject motion is apparent. In short, expect a very noticeable loss of detail on moving subjects in low-light conditions.

The Meizu Pro 7 Plus offers its best detail preservation in bright indoor conditions (100 Lux) and very bright outdoor conditions (1000 Lux), but in lower light, detail is noticeably affected both in static scenes and particularly in scenes containing subject movement, which is often very blurred.

Compared to competitors with a similar overall DxOMark Mobile score, such as the Lava Z25, the Meizu Pro 7 Plus records greater fine detail for static subjects in both indoor (100 Lux) and low-light (20 Lux) conditions. Comparison with top-end devices such as the Google Pixel 2, however, show that the more expensive device is (unsurprisingly) capable of greater definition in all conditions.

Crop of Meizu Pro 7 Plus at 100 Lux, on tripod

Crop of Lava Z25 at 100 Lux, on tripod

Crop of Google Pixel 2 at 100 Lux, on tripod

Crop of Meizu Pro 7 Plus at 20 Lux, on tripod

Crop of Lava Z25 at 20 Lux, on tripod

Crop of Google Pixel 2 at 20 Lux, on tripod

Noise

Meizu Pro 7 Plus

71

A good score overall for noise, which is particularly well-controlled in low light compared to many key competitors. The Meizu lost points for very noticeable noise in homogenous areas in outdoor pictures, however, such as in the plain blue sky below.

Although noise is handled reasonably well in low light, when shooting outdoors, luminance noise is very visible in areas of uniform color, such as the sky.

Some noise is visible in very low-light conditions (5 Lux), but remains very acceptable and is one of the strengths of the Meizu Pro 7 Plus.

Crop of Meizu Pro 7 Plus noise at 5 Lux

Crop of Lava Z25 noise at 5 Lux

Crop of Google Pixel 2 noise at 5 Lux

Artifacts

Meizu Pro 7 Plus

31

The Meizu Pro 7 Plus dropped many points because of corrupted images, image size variations, loss of acutance, cyan shift, and ringing. The most significant problem is the corrupted images, with some shots either partially or completely corrupted — occasionally displaying no image at all. Image size variations are also a little disconcerting, with the Meizu capturing many frames at the full 4000 x 3008px resolution, but recording some at a much lower 1024×768 px resolution for no apparent reason. Both problems occurred in all lighting conditions and in both lab and natural scene tests; we were unable to identify the cause of the inconsistencies.

Out of a consecutive series of 5 images of the same scene, the Meizu captured some exposures full size at 4000x3008px…

… while it recorded other exposures at a much lower 1024x768px resolution for no apparent reason.

A loss of sharpness across the frame is also significant, resulting in a large point deduction. Although many mobile devices display a loss of sharpness in the outer field, the Meizu Pro 7 Plus sometimes displays out-of-focus patches towards the center of the frame, too. We detected some vibrations of the lens, which are potentially caused by over-enthusiastic jabbing of the screen when taking a shot, so we advise a light touch and careful handling for more consistent sharpness.

A significant artifact problem for the Meizu Pro 7 Plus is inconsistent sharpness across the frame. Although many mobile devices suffer a loss of edge sharpness, the Meizu can display a loss of sharpness in random parts of the picture, including the center, which seriously affects image quality.

Flash

Meizu Pro 7 Plus

75

The Meizu Pro 7 Plus’s dual-tone flash module renders more neutral color using flash as the sole light source, with a noticeable yellow/green color cast evident in mixed-light shots. Good sharpness is challenging in flash pictures in all lighting conditions as well, but particularly with flash-only shots: portraits are noticeably soft, and also suffer from the red-eye effect and slightly red skin tones. The flash output is well-centered in the frame, but noticeable corner shading occurs, resulting in a significant buildup of luminance noise in the darker tonal regions.

Mixing flash with additional light sources (tungsten 5 Lux), white balance turns noticeably green and some autofocus instabilities are evident, and the device does not always accurately focus on the subject.

Zoom

Meizu Pro 7 Plus

28

With no second lens to provide a telephoto focal length, the Meizu Pro 7 Plus relies on digital zoom for getting in closer to your subjects. Our close-range (50mm) analysis in the lab using the 2x digital zoom shows that although there is some loss of detail at 100 Lux (indoor conditions) and 20 Lux (low-light conditions), the images remain acceptable overall. As you’d expect, the Meizu’s 2x zoom quality cannot keep up with the Google Pixel 2, but easily beats a mid-range device like the Lava Z25.

Crop of Meizu Pro 7 Plus at 100 Lux, 2x zoom

Crop of Lava Z25 at 100 Lux, 2x zoom

Crop of Google Pixel 2 at 100 Lux, 2x zoom

Crop of Meizu Pro 7 Plus at 20 Lux, 2x zoom

Crop of Lava Z25 at 20 Lux, 2x zoom

Crop of Google Pixel 2 at 20 Lux, 2x zoom

A more significant loss of detail occurs at 4x magnification, which you should avoid if you want the best results. Other problems such as artifacts and visible luminance noise both in homogenous areas in outdoor pictures, as well as in low-light images and portraits, also affect image quality.

Meizu Pro 7 Plus, mid-range (4x) zoom

Bokeh

Meizu Pro 7 Plus

30

The Meizu Pro 7 Plus’s bokeh simulation renders a pleasing shape to the spectral highlights in many areas of the background, which is its main strength. The blur intensity is very strong, however, so the overall effect is somewhat strange and not very natural-looking. Depth estimation failures also result in significant artifacts along the edges and around the portrait, with noticeable masking errors, and the blur is often applied inconsistently to foreground and background areas, again making the overall effect unnatural.

The Meizu Pro 7 Plus’s bokeh simulation has a very strong blur intensity, and although spectral highlights have a pleasant circular shape, the overall effect is not very natural. Many artifacts are visible around the subject, too, with depth estimation failures leading to inconsistent subject masking.

Video scores explained

The Meizu Pro 7 Plus achieved a lower score of 65 in our video analysis, compared to 74 for still photos. The overall Video score is calculated using the video sub-scores to give us some insight into the device’s strengths and weaknesses when shooting moving images: Exposure (59), Color (78), Autofocus (33), Texture (41), Noise (72), Artifacts (77), and Stabilization (51).

The device generally does a good with video exposure in well-balanced lighting conditions both outdoors and indoors, with well-exposed video under constant light sources in our lab analysis. As with stills, dynamic range is limited in video exposures, with a significant loss of detail evident when shooting high-contrast scenes, and videos are underexposed in very low-light conditions. Exposure adaptation during lighting changes can be abrupt, too, and is very noticeable in panning videos, when exposure tends to fluctuate, with over-shoots resulting in incorrectly exposed video for a few seconds.

The Meizu’s main strengths for video are its rich and well-saturated colors, which are particularly pleasant in outdoor movies. Its white balance is mainly accurate, with smooth adaptation, although some color cast instabilities are evident in indoor videos with walking movements. The main weakness for video is autofocus: although fast to lock on initially, it has a tendency to drop focus during recording. Significant focus hunting results in several seconds of out-of-focus video occurring frequently in clips. Stabilization is OK with handheld capture, but residual motion is evident when capturing video with basic walking movements in all lighting conditions.

Conclusion: Solid mid-range contender

Positioned at a significantly lower price point than many flagship devices, the Meizu Pro 7 Plus is competing price-wise with mid-range models from more established manufacturers — and it has a lot going for it, packing plenty of processing power, a large main screen, and an innovative second display as a stand-out feature.

For photography enthusiasts, the device’s dual RGB and monochrome sensors aim to improve image quality, and in the right conditions we achieved many successful pictures, with good exposure, color, and texture. However, dynamic range is a little limited, with HDR mode failing to activate automatically in default mode, and low-light images can be underexposed and lacking color. Images also show some artifacts and lens vibrations are seemingly the cause of inconsistent sharpness. That aside, the Meizu Pro 7 Plus gets most of the key stuff right for smartphone photographers, making it a solid contender in the mid-range market.
